OVERVIEW:
HYBRIDGEL series is specially designed for frequent deep cycle discharge. By using the specially designed active material and strong plates, the DZM/EVF series sealed lead acid battery offers reliable performance in big load situations and can deliver more than 450 cycles at 100% D.O.D . It is suitable for electric scooter, electric bicycle, electric wheel chairs, golf car, electric power vehicles, electric tool.
| Model | Voltage(V) | Capacity(AH) | Weight(KG) | Terminal | Size (mm) | ||
|---|---|---|---|---|---|---|---|
| Length | Width | Height | |||||
| 6-DZM-10 | 12 | 10 | 3.8 | F2 | 151 | 98 | 101 |
| 6-DZM-12 | 12 | 12 | 4.2 | F2 | 151 | 98 | 101 |
| 6-DZM-20 | 12 | 20 | 6.5 | F18 | 181 | 77 | 170 |
| 6-DZM-33 | 12 | 33 | 11.3 | F14/L16 | 195 | 130 | 180 |
| 6-EVF-32 | 12 | 30 | 9.8 | F10 | 267 | 77.5 | 171 |
| 6-EVF-38 | 12 | 38 | 12.1 | F10 | 221 | 106 | 171 |
| 6-EVF-40 | 12 | 40 | 11.5 | F12 | 194 | 131 | 169 |
| 6-EVF-45 | 12 | 45 | 12.5 | F12 | 223 | 120 | 174 |
| 6-EVF-50 | 12 | 50 | 15.8 | F12 | 206 | 166 | 160 |
| 6-EVF-55 | 12 | 55 | 18.5 | F12/L20 | 229 | 138 | 235 |
| 6-EVF-60 | 12 | 60 | 20.5 | F12/L20 | 260 | 169 | 235 |
| 6-EVF-65 | 12 | 65 | 19.4 | F12 | 223 | 175 | 175 |
| 6-EVF-70 | 12 | 70 | 24.5 | F12/L20 | 260 | 169 | 235 |
| 6-EVF-90 | 12 | 90 | 31.0 | F12/L20 | 306.5 | 168.5 | 235 |
| 6-EVF100 | 12 | 100 | 35.0 | F12/L20 | 328 | 172 | 222 |
| 6-EVF-120 | 12 | 120 | 41.5 | F12/L20 | 407 | 177 | 225 |
| 6-EVF-135 | 12 | 135 | 43.0 | F12/L20 | 340 | 173 | 285 |
| 6-EVF-150 | 12 | 150 | 51.0 | F12/L20 | 483 | 170 | 240 |
| 3-EVF-200 | 6 | 200 | 35.0 | F12 | 260 | 180 | 278 |
